Although each jurisdiction is different, their backbone is virtually the same. These tips may seem elementary, however, they tend to be forgotten, which delays the submission of some plans.

---

Cover and all 'A' sheets should bear the original seal and signature of the architect.

Cover sheets should have a vicinity and key map, showing your project in relationship to the rest of the spaces and/or buildings.

Cover sheet should ALWAYS list project name and specific/exact address.

For in-line and/or alterations to existing buildings, cover sheet should have the following code analysis:

	Existing	Proposed
Use group(BOCA, art) Type of Construction Height/No. of Stories High Rise? Covered Mall? Area/SF of Renovation	______ ______ ______ ______ ______ ______	______ ______ ______ ______ ______ ______









All mechanical, electrical and plumbing sheets should bear the original seal and signature of a Professional Engineer, NOT the architect.

Show occupant loads based on current editions of BOCA and NFPA Life Safety.

Provide electrical panel schedule and mechanical CFM, inside/outside air schedules.

Make sure the general contractor and the subs have all required licenses for each project.
